BOSE DESIGNMAX DM5C Black
Product details
DesignMax DM5C speakers offer a great sound and they have a very elegant design, suited for any commercial space. The 12 models available in the range offer the possibility to easily design quality audio solutions.
| Răspuns în frecvență (-3 dB) |
70 - 17.000 Hz
|
| Gama de frecvență (-10 dB) |
60 - 20.000 Hz
|
| Dispersie |
conica (H xV)
|
| Putere |
50W
|
| Putere - vârf |
200 W
|
| Sensibilitate |
88 dB
|
| Presiune sonoră maximă (SPL) calculat 1m |
105 dB
|
| Impedanța |
8 ohm (no transformer)
|
| Grilă - material fabricație |
Magnetically attached perforated steel, powder-coated finish, paintable, with safety-tether
|
| Grilă |
Magnetically attached perforated steel, powder-coated finish, paintable, with safety-tether
|
| Logo |
Rotatable, removable
|
| Culoare |
black, white (paintable)
|
| Mediu |
Indoor only
|
| Standarde siguranța |
UL-1480A, S5591/ UL Listed, in compliance with UL2043 for plenum-space installation, NFPA70 & NFPA90-A, CE compliant
|
| Temperatura (mediu interior/exterior) la utilizare |
0 °C to 50 °C (32 °F to 122 °F)
|
| Conectori |
Euroblock 6-pin connector with loop-through, front-baffle mounted. Accepts 18 AWG (0.8 mm2) to 14 AWG (2.5 mm2) size wire.
|
| Intrare fire |
Single top wire entry point knockouts, allows for 9.5 mm (3/8 in) conduit
|
| Montaj |
interior
|
| Dimensiuni |
303 mm (Grille diamether) × 205 mm (Depth) / 11.9 in × 8.1 in
|
| Dimensiune carcasă în tavan |
243 mm (Diameter) × 192 mm (Depth)
|
| Diametru decupare |
250 mm (9.8 in)
|
| Greutate netă |
4.45 kg (9.6 lb) / single
|
| Greutate brută |
13.2 kg (29.0 lb) / pair
|
| Cod produs |
829683-0110 negru, 829683-0210 alb
|
